Handled Eccentric Cam Ascenders
Stamped Frame

This section includes mechanical ascenders consisting of a shell or frame and an eccentric cam assembly attached to the shell/frame at a single pivot point. The shell/frame is open on one side to allow admittance of the standing rope. The shell/frame below the cam is enlarged to provide a handle. No sling attachment points are provided on the cam.

These ascenders are generally larger and heavier than the handleless eccentric cam ascenders; conversely, they are easier to manipulate, particularly with gloved hands. I don't normally wear gloves ahile ascending (except in cold conditions), but many people prefer to do so.

I split the Handled Eccentric Cam Ascenders into these four groups:

Stamped frame ascenders are popular, to a large part because of their light weight. They invariably have an added plastic, rubber, or similar grip, and when well designed, these can be quite comfortable. Unfortunately, stamped frame ascenders are not as rugged as their Milled Frame cousins. There have been several failures where an ascender frame bent when carelessly placed at a pit lip and loaded; however, I'm not aware of any of these leading to fall accidents. Choosing an ascender with a thicker frame and appropriate reinforcing ribs helps reduce the risk.

In the ID column and chart, I used a red background for cast-frame ascenders, green for milled-frame ascenders, and blue for stamped-frame ascenders. Magenta indicates a two-rope ascender.

Gallery

Image ID Device Description Acquired Weight Height Width Thickness Std. volume Channel Diameter Cam Angle Tooth Pattern
Advanced Base Camp 211
2205
Advanced Base Camp LH & RH, stamped frame, rubber grips, pear top & 2 round bottom holes, stamped cam stop, hybrid cam /w sloping teeth, double pin safety with pivot on side of cam
  • The Outdoor Store, 2007
  • Bob Thrun Collection, 2017
217 181 91 32 519 15.3 31° (3.4.2)(1H1.2)^3(3.2)
Alpidex Move Up 2308 Alpidex Move Up LH & RH, stamped frame, oval & D top and 2 round bottom holes, stamped cam stop, braced cam /w straight teeth, tab safety below cam David Wain, 2017 239 205 103 27 570 17.1 30° (3)(4.H)^2(3.H)^2(3.2.2)
Altius, Version A 123 Altius, Version A RH, stamped frame, plastic grip, oval + round top & round bottom holes, semi-open web cam /w sloping teeth, knob safety below cam Unidentified caver, 1997 207 199 92 26 477 14.9 26° (2)(3.4)^2(3.2)^2(1)
Altius, Version B 257 Altius, Version B LH, stamped frame, plastic grip, oval + round top & round bottom holes, semi-open web cam /w sloping teeth, knob safety below cam C. Burford 206 198 91 26 471 14.9 26° (2)(3.4)^2(3.2)^2(1)
Альтурс, Version A 2340 Al'turs (Альтурс), Version A RH, painted stamped frame, oval & round top holes, round bottom hole, pin cam stop, plated hybrid cam /w sloping teeth, screw-pin safety below cam Alexander Starkov, 2017 215 193 87 29 491 17.2 25° (4.1)(2S2.1S1)^2(1S1)^3(1.2)
Альтурс, Version B 2164
2905
Al'turs (Альтурс), Version B RH, painted stamped frame, oval & round top holes, round bottom hole, pin cam stop, hybrid cam /w sloping teeth, screw-pin safety below cam
  • Bob Thrun Collection, 2017
  • Ed Sira, 2019
199 193 91 27 471 15.9 24° (4.1)(2S2.1S1)^2(1S1)^3(1.2)
Альтурс, Version C 2165 Al'turs (Альтурс), Version C RH, painted stamped frame, oval & round top holes, round bottom hole, pin cam stop, plated hybrid cam /w sloping teeth, screw-pin safety below cam Bob Thrun Collection, 2017 193 193 90 28 476 15.9 25° (4.1)(2S2.1S1)^2(1S1)^3(1.2)
Альтурс, Version D 1942 Al'turs (Альтурс), Version D RH, painted stamped frame, oval & round top holes, round bottom hole, pin cam stop, hybrid cam /w sloping teeth, screw-pin safety below cam Philipp Molzer, 2013 191 193 89 28 481 16.0 22° (3.2)(1S1)^1(2.1.2)
Anthron AD-10, Version A 2187 Anthron AD-10, Version A RH, stamped frame, oval & round top holes, round lower hole, braced cam /w sloping teeth & side mud grooves, pin safety below cam Bob Thrun Collection, 2017 214 197 94 28 523 15.0 24° (3.2)^2(1.2)^2(B)
Anthron AL-15, Version B 155 Anthron AL-15, Version B LH, stamped frame, oval & round top holes, 2 round lower holes, braced cam /w sloping teeth & side mud grooves, pin safety below cam Inner Mountain Outfitters, 2001 217 200 92 32 590 15.0 24° (3.2)^2(1.2)^2(B)
Anthron AD-10, Version C 2188 Anthron AD-10, Version C RH, stamped frame, oval & round top holes, 2 round lower holes, barred cam /w side mud grooves, sloping teeth, safety /w pin on cam Bob Thrun Collection, 2017 217 200 92 32 590 15.0 24° (3.2)^2(1.2)^2(B)
Anthron AD-10 & AL-15, Version D 156/2189 Anthron AD-10 & AL-15, Version D LH (AL-15) & RH (AD-10), stamped frame, oval & round top holes, 2 round lower holes, plated braced cam /w sloping teeth, pin safety below cam
  • Inner Mountain Outfitters, 1999
  • Bob Thrun Collection, 2017
217 200 92 32 590 15.0 24° (3.2)^2(1.2)^2(B)
Anthron AD-10 & AL-15, Version E 2113/2114 Anthron AD-10 & AL-15, Version E LH (AL-15) & RH (AD-10), stamped frame, oval & round top holes, 2 round lower holes, braced cam /w sloping teeth & side mud grooves, pin safety below cam Bob Thrun Collection, 2017 205 202 92 28 524 15.0 24° (3.2)^2(1.2)^2(B)
Anthron AD-10 & AL-15, Version F 194/195 Anthron AD-10 & AL-15, Version F LH (AL-15) & RH (AD-10), stamped frame, oval & round top holes, 2 round lower holes, braced cam /w sloping teeth & side mud grooves, pin safety below cam Inner Mountain Outfitters, 2005 215 200 91 31 562 15.0 24° (3.2)^2(1.2)^2(B)
Anthron VauDe AD-10 & AL-15, Version A 133/134
2190/2191
Anthron VauDe AD-10 & AL-15 LH (AL-15) & RH (AD-10), stamped frame, oval & round top holes, round lower hole, braced cam /w sloping teeth & side mud grooves, pin safety below cam
  • Inner Mountain Outfitters, 1999
  • Bob Thrun Collection, 2017
198 195 93 34 608 15.0 24° (3.2)^2(1.2)^2(B)
Asol 2323 Asol, Version A RH, stamped frame, round top & 2 round bottom holes, hybrid cam /w sloping teeth, tab safety below cam Kangjin Liao, 2017 205 191 89 27 452 15.9 31° (2.4)(1S1.2S2)^2(1S1)(2.3)
Asol 2358 Asol, Version B LH, stamped frame, oval top & bottom holes, semi-web cam /w sloping teeth, plastic safety below cam Kangjin Liao, 2018 175 195 91 24 426 14.9 30° (3.4)((1S1)^2(2S2)(1S1)^3(2.3.2.2.3)
Beal Hands Up 2052 Beal Hands Up RH, stamped frame, oval top hole, irregular lower holes, hybrid cam /w sloping teeth, knob safety below cam Expé-Spelemat, 2016 271 234 105 29 697 15.7 33° (3.4)(1S1.2S2)^2(3.2.1)(BB)
Венто 2986 Венто RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, open-web cam /w sloping teeth, tab safety below cam Artyom Babin (Артём Бабин), 2020 240 203 92 25 469 15.8 28° (3)^3(1S1)^5(3)^2
Black Diamond Index 1995/1996 Black Diamond Index RH, stamped frame, rubber grips, round/oval top & 2 round bottom holes, drooped cam /w cutouts & sloping teeth, plastic safety below cam Backcountry Gear, 2015 205 188 90 28 478 14.8 32° (3.4)(1S1)^10(2.1.2)
Blanzo 2325 Blanzo LH & RH, stamped frame, rubber grips, oval top & round bottom holes, hybrid cam /w straight teeth, push-button safety latch on cam Kangjin Liao, 2017 217 201 98 33 651 14.2 34° (1.2)(3.2)^4(1)
Brasovia 1589 Brasovia LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, asymmetrical open-web cam /w sloping teeth, tab safety below cam Brasovia, 2012 241 203 92 25 460 15.8 27° (3)^3(1H1)^5(3)^2
Camnal 2977/2978 Camnal LH & RH, stamped frame, rubber grips, oval top & 2 round bottom holes, semi-web cam /w sloping teeth, plastic safety below cam shenzhenshi oucong dianzi keji youxian gongsi, 2020 203 192 95 26 472 14.6 32° 3.4.1S1.2S2.2S2.1S1.2S2.3.2.3
Camp Pilot, Version A 151 Camp Pilot, Version A LH & RH, stamped frame, rubber grips, oval top & round bottom holes, perforated plate cam /w straight teeth, push-button safety latch on cam K&R Adventure Gear, 2001 220 199 100 32 631 13.5 31° (2)(1D1)^7(1)
Camp Pilot, Version B 3452 Camp Pilot, Version B LH, stamped frame, rubber grips, oval top & round bottom holes, hybrid cam /w straight teeth, push-button safety latch on cam Curt T. Fladager, 2021 216 200 100 32 647 14.7 35° (1)(2.3)^4(2.1)
Camp Pilot, Version C 2206 Camp Pilot, Version C LH & RH, stamped frame, rubber grips, oval top & round bottom holes, hybrid cam /w straight teeth, push-button safety latch on cam Bob Thrun Collection, 2017 209 200 99 32 630 14.5 35° (1)(2.3)^4(2.1)
Camp Turbohand 2386/2943 Camp Turbohand LH & RH, stamped frame, rubber grips, oval top & 2 round bottom holes, drooped cam /w straight teeth, tab safety below cam Rock N Rescue, 2019 172 185 94 22 378 14.0 40° (3.2)(1H1)(2.2.3.H.2.2.1)(1H1)(2.2.3)
Camp Turbohand 2944 Camp Turbohand Pro LH & RH, stamped frame, rubber grips, oval top & 2 round bottom holes, lower guide, drooped cam /w straight teeth, tab safety below cam Omni Pro Gear, 2019 185 185 94 22 378 14.0 40° (3.2)(1H1)(2.2.3.H.2.2.1)(1H1)(2.2.3)
Chkalovsky Aviation Plant, Version A 122 Chkalovsky Aviation Plant, Version A RH, stamped frame, plastic grip, round top & bottom holes, open-web cam /w sloping flat teeth, safety lever in cam channel John E. Weinel, Inc., 1996 234 223 102 30 682 16.0 25° (2.3)^2(2)
Chkalovsky Aviation Plant, Version B 3445 Chkalovsky Aviation Plant, Version B RH, stamped frame, plastic grip, round top & bottom holes, open-web cam /w sloping flat teeth, safety lever in cam channel Artyom Babin (Артём Бабин), 2021 233 221 103 30 671 15.8 26° (2.3)^2(3)
Climb Tech 1932/1972
2197
Climb Tech LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, asymmetrical open-web cam /w sloping teeth, tab safety below cam
  • Climb Tech, 2012/2014
  • Omni Pro Gear, 2012/2014
  • Bob Thrun Collection, 2017
238 203 93 26 492 15.8 27° (3)^3(1H1)^5(3)^2
Climb X X Ascender 1997 Climb X X Ascender LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, open-web cam /w sloping teeth, tab safety below cam Climb X, 2015 237 202 94 25 480 14.9 28° (3)^3(1S1)^5(3)^2
Climbing Technology (Knot & Rope) 1950/1951 Climbing Technology Amelia
(Knot & Rope)
LH & RH, stamped frame, rubber grips, pear top & 2 round bottom holes, stamped cam stop, hybrid cam /w sloping teeth, double pin safety with pivot on side of cam Knot & Rope Supply on Amazon.com, 2012 213 189 91 32 551 15.6 31° (3.4.2)(1H1.2)^3(3.2)
Climbing Technology Quick'Arbor (separated) 1990 Climbing Technology Quick'Arbor (separated) Separated LH & RH, stamped frame, rubber grips, 2 pear top & 5 round bottom holes, plastic rope retainers, stamped cam stops, ,  WesSpur Tree Equipment, 2015 225 195 90 35 606 15.7 31° (3.4.2)(1H1.2)^3(3.2)
Climbing Technology Quick Roll 2082/2183 Climbing Technology Quick Roll LH & RH, stamped frame, rubber grips, pear top & 2 round bottom holes, stamped cam stop, hybrid cam /w sloping teeth, double pin safety with pivot on side of cam
  • R&L Supply LLC / Amazon.com, 2019
  • Lawrence Thomas, Innovative Industries Unlimited LLC, 2019
259 189 95 39 693 15.7 31° (3.4.2)(1H1.2)^3(3.2)
Climbing Technology Quick'Up, Version A 2008
2011
Climbing Technology Quick'Up, Version A LH & RH, stamped frame, rubber grips, pear top & 2 round bottom holes, stamped cam stop, hybrid cam /w sloping teeth, knurled double pin safety with pivot on side of cam
  • Croque Montagne, 2015
  • Expé-Spelemat, 2015
214 189 90 32 552 15.7 31° (3.4.2)(1H1.2)^3(3.2)
Climbing Technology Quick'Up, Version B 2012
2954
Climbing Technology Quick'Up, Version B LH & RH, stamped frame, rubber grips, pear top & 2 round bottom holes, stamped cam stop, hybrid cam /w sloping teeth, knurled double pin safety with pivot on side of cam
  • Expé-Spelemat, 2015
  • Boardparadise, 2019
216 189 91 33 571 15.7 31° (3.4.2)(1H1.2)^3(3.2)
Climbing Technology Quick'Up+ 2976/2969 Climbing Technology Quick'Up+ RH, stamped frame, rubber & plastic grips, pear top & 2 round bottom holes, stamped cam stop, hybrid cam /w sloping teeth, knurled double pin safety with pivot on side of cam Amazon.com, 2020 218 189 92 30 520 15.7 31° (3.4.2)(1H1.2)^3(3.2)
Clog Expedition, Version B 2159 Clog Expedition, Version A RH, stamped frame, rubber grips, round top & bottom holes, open-web cam /w straight teeth, safety lever in cam channel Bob Thrun Collection, 2017 238 195 109 25 521 14.7 22° (4.5)^4(4.3)^4
Clog Expedition, Version B 24
1910
2158
Clog Expedition, Version B LH & RH, stamped frame, rubber grips, round top & bottom holes, open-web cam /w straight teeth, safety lever in cam channel
  • Mountaineering Outfitters, 1980
  • Stuart Polack, 2012
  • Bob Thrun Collection, 2017
237 195 109 25 521 14.7 22° (4.5)^4(4.3)^4
Clog Expedition, Version C 2156 Clog Expedition, Version C LH, stamped frame, plastic grips, round top holes, open-web cam /w straight teeth, safety lever in cam channel Bob Thrun Collection, 2017 222 195 111 24 514 14.3 22° (4.5)^4(4.3)^4
Clog Expedition, Version D 25
2157
Clog Expedition, Version D LH & RH, stamped frame, plastic grips, round top holes, open-web cam /w straight teeth, safety lever in cam channel
  • Avalanche, 1978
  • Bob Thrun Collection, 2017
230 195 107 25 511 14.3 22° (4.5)^4(4.3)^4
Clog Expedition, Version E 1505R
1567
Clog Expedition, Version E LH & RH, stamped frame, plastic grips, round top & bottom holes, open-web cam /w straight teeth, safety lever in cam channel
  • Jeanne Biggs, 2009
  • Mike Ford, 2012
243 196 105 28 514 16.0 22° (4.5)^4(4.3)^4
Clog Expedition, Version F 1505L Clog Expedition, Version F LH, stamped frame, plastic grips, round top & bottom holes, open-web cam /w straight teeth, safety lever in cam channel Jeanne Biggs, 2009 243 196 105 28 514 16.0 22° (4.5)^4(4.3)^4
Clog Expedition, Version G 171
1555
2007
Clog Expedition, Version G LH & RH, stamped frame, plastic grips, round top & bottom holes, open-web cam /w straight teeth, safety lever in cam channel
  • Terry Wilkins, 2004 (left)
  • Lawrence Rowles, 2011 (pair)
  • Steve Swanchak, 2015 (pair)
237 195 105 28 564 16.0 22° (4.5)^4(4.3)^4
Clog Expedition, Version H 218
2166
Clog Expedition, Version H LH & RH, stamped frame, plastic grips, round top & bottom holes, open-web cam /w straight teeth, plastic safety lever in cam channel
  • Anthony Morton, 2007
  • Bob Thrun Collection, 2017
228 195 104 25 514 16.3 23° (4.5)^4(4.3)^4
Clog Expedition, Version I 26
172
2167
Clog Expedition, Version I LH & RH, stamped frame, plastic grips, round top hole, pin cam stop, open-web cam /w straight teeth, plastic safety lever in cam channel
  • Exkursion, 1993 (pair)
  • Terry Wilkins, 2004 (right)
  • Bob Thrun Collection, 2017
236 194 105 26 530 16.5 22° (4.5)^4(4.3)^4
CMI Expedition, Version A 130
2226
3430
CMI Expedition, Version A LH & RH, stamped frame, plastic grips, round top & 2 round bottom holes, pin cam stop, hybrid cam /w straight teeth, plastic safety lever in cam channel
  • Inner Mountain Outfitters, 1998
  • Bob Thrun Collection, 2017
  • Kristen Ongoy (3 LH), 2021
262 206 107 32 705 16.5 25° (4.3)^5(4)
CMI Expedition, Version B 3431 CMI Expedition, Version B RH, stamped frame, plastic grips, round top & 2 round bottom holes, pin cam stop, hybrid cam /w straight teeth, plastic safety lever in cam channel Kristen Ongoy, 2021 264 206 107 32 705 16.5 25° (4.3)^5(4)
CMI Expedition, Version C 3437 CMI Expedition, Version C LH & RH, stamped frame, plastic grips, round top & 2 round bottom holes, pin cam stop, hybrid cam /w straight teeth, safety lever in cam channel CMI, 2021 259 208 104 32 701 16.5 25° (4.3)^5(4)
CMI Expedition Double, Version A 239
2227
CMI Expedition Double, Version A LH & RH, stamped frame, dual handle, plastic grips, round top & 2 round bottom holes, pin cam stop, hybrid cam /w straight teeth, plastic safety levers in cam channel, QR pin safety
  • Ed Yazzie, 2008
  • Bob Thrun Collection, 2017
392 208 178 35 1292 16.5 25° (4.3)^5(4)
CMI Expedition Double, Version B 3438 CMI Expedition Double, Version B LH & RH, stamped frame, dual handle, plastic grips, round top & 2 round bottom holes, pin cam stop, hybrid cam /w straight teeth, safety lever in cam channel, QR pin safety CMI, 2021 403 208 179 38 1392 16.5 25° (4.3)^5(4)
Cypher 2954 Cypher, Version A LH, stamped frame, rubber grips, pear top & 2 round bottom holes, stamped cam stop, hybrid cam /w sloping teeth, knurled double pin safety with pivot on side of cam Boardparadise, 2019 220 189 92 30 518 15.6 26° (3.4.2)(1H1.2)^3(3.2)
Cypher 2968/3409 Cypher, Version B LH & RH, stamped frame, rubber & plastic grips, pear top & 2 round bottom holes, stamped cam stop, hybrid cam /w sloping teeth, knurled double pin safety with pivot on side of cam
  • Buffalo Gap Outfitters, 2020
  • Cypher Climbing, 2021
216 189 92 30 521 15.6 26° (3.4.2)(1H1.2)^3(3.2)
Edelrid Elevator 220 Edelrid Elevator LH & RH, stamped frame, rubber grips, pear top & 2 round bottom holes, stamped cam stop, hybrid cam /w sloping teeth, double pin safety with pivot on side of cam Walkhigh Mountaineering, 2007 214 189 90 35 588 15.4 31° (3.4.2)(1H1.2)^3(3.2)
Edelweiss AS16 2369 Edelweiss AS16 RH, stamped frame, oval top hole, irregular lower holes, hybrid cam /w sloping teeth, knob safety below cam Got Your Gear, 2018 263 234 105 29 697 15.7 33° (3.4)(1S1.2S2)^2(3.2.1)(BB)
Epic Peak 3413, 3414 Epic Peak RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, semi-open-web cam /w sloping teeth, tab safety below cam Epic Gear USA, 2021 246 202 94 29 543 15.1 27° (3)^3(1S1)^5(3)^2
Fixe Capitan 258 Fixe Capitan LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, stamped cam stop, asymmetrical open-web cam /w sloping teeth, tab safety below cam Au Vieux Campeur, 2008 238 202 93 25 588 15.6 30° (3)^3(1S1)^5(3)^2
Fusion Voltron, Version A 2359 Fusion Voltron, Version A RH, stamped frame, oval top & bottom holes, semi-web cam /w sloping teeth, plastic safety below cam World Lifestyle Shop, 2018 173 195 94 25 461 14.9 30° (3.4)((1S1)^2(2S2)(1S1)^3(2.3.2.2.3)
Fusion Voltron, Version B 2910/2970 Fusion Voltron, Version B LH & RH, stamped frame, oval top & bottom holes, semi-web cam /w sloping teeth, plastic safety below cam
  • World Lifestyle Shop, 2019
  • Amazon.com, 2020
175 195 92 25 450 14.9 30° (3.4)((1S1)^2(2S2)(1S1)^3(2.3.2.2.3)
GM Climbing, Version A 2322 GM Climbing, Version A LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, open-web cam /w sloping teeth, plastic-covered tab safety below cam 5star-distribution, 2017 249 202 94 26 487 15.4 29° (3)^3(1S1)^5(3)^2
GM Climbing, Version B 3423 GM Climbing, Version B LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, semi-open-web cam /w sloping teeth, plastic-covered tab safety below cam Amazon.com, 2021 250 203 94 24 454 15.3 27° (3)^3(1S1)^5(3)^2
Good Makings 1973 Good Makings LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, open-web cam /w sloping teeth, tab safety below cam Yungfeng Xiao, 2014 240 202 94 25 476 15.4 29° (3)^3(1S1)^5(3)^2
GrandWall 1998
2193
GrandWall LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, open-web cam /w sloping teeth, tab safety below cam
  • GrandWall Equipment, 2015
  • Bob Thrun Collection, 2017
237 202 94 25 480 14.9 28° (3)^3(1S1)^5(3)^2
Grivel A&D, Version A 1981/1982
2087/2088
Grivel A&D, Version A LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, rappel/belay slot, asymmetrical open-web cam /w straight teeth, tab safety below cam
  • Backcountry Gear, 2014
  • Bob Thrun Collection, 2017
257 204 97 23 458 16.0 28° (3)^3(1S1)^5(3)^2
Grivel A&D, Version B 2337/2974 Grivel A&D, Version B LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, rappel/belay slot, asymmetrical open-web cam /w straight teeth, large ring safety below cam
  • Sofia Goumas, 2017
  • Amazon.com, 2020
258 204 97 34 677 15.9 28° (3)^3(1S1)^5(3)^2
Grivel A1 2327/2980 Grivel A1 LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, asymmetrical open-web cam /w sloping teeth, large ring safety below cam
  • RH: TradeInn, 2017
  • LH: Banana Fingers, 2021
256 203 99 36 725 16.4 28° (3)^3(1S1)^5(3)^2
heightec-PMI Pulsar D40, Version A 256
2093
heightec-PMI Pulsar D40, Version A RH, stamped frame, oval upper holes, 2 round lower holes, pin cam stop, open-web cam /w straight teeth, pin safety below cam
  • On Rope 1, 2008
  • Bob Thrun Collection, 2017
228 196 91 26 465 15.4 26° (1.2^3)^2(1.2)^2(B)
heightec-PMI Pulsar D40, Version B 1500
2094
2212
heightec-PMI Pulsar D40, Version B LH & RH, stamped SS frame, oval upper holes, 2 round lower holes, pin cam stop, open-web cam /w straight teeth, plastic safety below cam
  • On Rope 1, 2009
  • Bob Thrun Collection, 2017
  • Bob Thrun Collection, 2017
221 196 91 29 465 15.4 26° (1.2^3)^2(1.2)^2(B)
Hugh Banner, Version A 1541 Hugh Banner, Version A LH, stamped frame, rubber grips, oval top & round bottom holes, open-web cam /w straight teeth, safety lever in cam channel G. Wright, 2010 241 192 99 28 537 17.4 26 (4.5)^4(4.3)^4
Hugh Banner, Version B 199 Hugh Banner, Version B LH & RH, stamped frame, rubber grips, oval top & round bottom holes, hybrid cam /w straight teeth, pin safety with pivot on side of cam John Bull Clothing, 2005 273 191 93 39 691 18.3 26° (4.5)^4(4.3)^4
Russian Interalp 2341 Interalp (Russian) RH, stamped frame, plastic grip, oval + round top & round bottom holes, open-web cam /w sloping teeth, knob safety below cam 1997 207 198 91 24 432 14.9 26° (3.4)^3(3.2)^2(1)
Izhevsk Mechanical Plant Peak (ПИК) 3444 Izhevsk Mechanical Plant Peak (ПИК) RH, stamped frame, plastic grip, round top & bottom holes, open-web cam /w straight teeth, safety lever in cam channel Artyom Babin (Артём Бабин), 2021 286 234 103 33 783 16.5 20° (4)^13
Kong-Bonaiti 223 Kong-Bonaiti LH & RH, 2-piece stamped frame riveted together, oval & D top holes, round bottom hole, stamped cam stop, asymmetrical open-web cam /w sloping teeth, pin safety below cam Brian Greco, 2007 232 209 92 29 559 15.4 30° (3)(4.H)^2(3.H)^2(2.2.1)
Kong-Bonaiti Lift 139
2199
2202
Kong-Bonaiti Lift LH & RH, stamped frame, oval & D top and 2 round bottom holes, stamped cam stop, asymmetrical open-web cam /w sloping teeth, pin safety below cam
  • Inner Mountain Outfitters, 1999
  • Bob Thrun Collection, 2017
  • Bob Thrun Collection, 2017
223 199 88 27 473 15.4 30° (3)(4.H)^2(3.H)^2(3.2.2)
Kong-Bonaiti Modular With Caver Handle 22
1566
1579
Kong-Bonaiti Modular With Caver Handle LH & RH, modular/w caver handle, stamped frame, round & D top holes, round bottom hole, stamped cam stop, asymmetrical open-web cam /w sloping teeth, pin safety below cam
  • Inner Mountain Outfitters, 1992
  • Geoffrey Storey, 2012
231 188 95 37 661 15.4 30° (3)(4.H)^2(3.H)^2(2.2.1)
Kong-Bonaiti Modular With Climber Handle 23
230
269
2381
3407
Kong-Bonaiti Modular With Climber Handle LH & RH, modular /w climber handle, stamped frame, round & D top holes, round bottom hole, stamped cam stop, asymmetrical open-web cam /w sloping teeth, pin safety below cam
  • Inner Mountain Outfitters, 1993
  • Curtis Gray, 2007
  • Chris Christensen, 2009
  • Jack R Reynolds, 2019
  • Avi Basri, 2021
234 208 92 37 708 15.4 30° (3)(4.H)^2(3.H)^2(2.2.1)
Kong-Bonaiti Modular With Dual Handle 23 Kong-Bonaiti Modular With Dual Handle LH & RH, modular, stamped frame, round & D top holes, round bottom hole, stamped cam stop, asymmetrical open-web cam /w sloping teeth, pin safety below cam Inner Mountain Outfitters, 1993 321 208 159 37 1224 15.4 30° (3)(4.H)^2(3.H)^2(2.2.1)
Kong Lift, Version A 2200 Kong Lift, Version A LH & RH, stamped frame, oval & D top and 2 round bottom holes, stamped cam stop, asymmetrical open-web cam /w sloping teeth, pin safety below cam Bob Thrun Collection, 2017 216 200 97 26 500 15.4 30° (3)(4.H)^2(3.H)^2(3.2.2)
Kong Lift, Version B 2016/2017 Kong Lift, Version B LH & RH, stamped frame, oval & D top and 2 round bottom holes, stamped cam stop, asymmetrical open-web cam /w sloping teeth, tab safety below cam
  • SiteLead, Inc., 2015
  • unbeatablesale.com, 2015
229 199 96 25 479 15.4 30° (3)(4.H)^2(3.H)^2(3.2.2)
Kong Procave 249
2201
Kong Procave LH & RH, stamped frame, 2 round bottom holes, asymmetrical open-web cam /w sloping teeth, tab safety below cam
  • Expé-Spelemat, 2008
  • Bob Thrun Collection, 2017
201 161 119 27 523 15 29° (3)(4.H)^2(3.H)^2(3.2.2)
Kratos 2355 Kratos LH & RH, stamped frame, 2 round bottom holes, asymmetrical open-web cam /w sloping teeth, tab safety below cam Ondřej Belica / Climbing CZ sro, 2017 219 207 90 27 509 16.6 30° (3)^3(2)^2(1s1)^3(3)^2
Krok, Version A 1533 Krok, Version A RH, stamped frame, rubber grips, oval top & 2 round bottom holes, hybrid cam /w straight teeth, double-pin safety with pivot on side of cam Gear4Rocks, 2010 204 191 93 31 588 16.6 34° (3.2)(2.2.H)^3(2.2.3.2)
Krok, Version B 1565 Krok, Version B LH, stamped frame, rubber grips, oval top & 2 round bottom holes, hybrid cam /w straight teeth, double-pin safety with pivot on side of cam Gear4Rocks, 2010 206 191 93 31 588 16.6 34° (3.2)(2.2.H)^3(2.2.3.2)
Krok, Version C 2090 Krok, Version C RH, stamped frame, rubber grips, oval top & 2 round bottom holes, hybrid cam /w straight teeth, double-pin safety with pivot on side of cam Bob Thrun Collection, 2017 203 193 92 31 548 16.6 34° (3.2)(2.2.H)^3(2.2.3.2)
Krok, Version D 2089 Krok, Version D LH, stamped frame, rubber grips, oval top & 2 round bottom holes, hybrid cam /w straight teeth, double-pin safety with pivot on side of cam Bob Thrun Collection, 2017 203 193 92 31 548 16.6 34° (3.2)(2.2.H)^3(2.2.3.2)
Krok, Version E 1580/1581 Krok, Version E LH & RH, stamped frame, rubber grips, oval top & 2 round bottom holes, hybrid cam /w straight teeth, double-pin safety with pivot on side of cam Gear4Rocks, 2012 229 190 91 29 496 16.2 32° (3.2)(2.2.H)^3(2.2.3.2)
Krok, Version F 2995/2996 Krok, Version F LH & RH, stamped steel frame, rubber grips, oval top & 2 round bottom holes, hybrid cam /w straight teeth, double-pin safety with pivot on side of cam Krok, 2021 277 190 92 29 513 15.7 31° (3.2.2)(1H1.2)^3(2.3.2)
Krok, Version G 2997/2998 Krok, Version G LH & RH, stamped steel frame, rubber grips, oval top & 2 round bottom holes, seven hex holes, hybrid cam /w straight teeth, double-pin safety with pivot on side of cam Krok, 2021 269 190 91 30 528 15.7 31° (3.2.2)(1H1.2)^3(2.3.2)
Krok, Version H 2999 Krok, Version H LH, stamped frame, rubber grips, oval top & 2 round bottom holes, hybrid cam /w straight teeth, reflex (Рефлекс) trigger safety with pivot on side of cam Krok, 2021 240 191 93 35 617 16.5 31° (3.2.2)(1H1.2)^3(2.3.2)
Krok, Version I 3400 Krok, Version I RH, stamped steel frame, rubber grips, oval top & 2 round bottom holes, hybrid cam /w straight teeth, reflex (Рефлекс) trigger safety with pivot on side of cam Krok, 2021 284 190 93 31 551 15.8 31° (3.2.2)(1H1.2)^3(2.3.2)
Krok, Version J /w Elevon + 3401 Krok, Version J /w Elevon + RH, stamped frame, rubber grips, oval top & 2 round bottom holes, assist pulley on back, hybrid cam /w straight teeth, reflex (Рефлекс) trigger safety with pivot on side of cam Krok, 2021 304 191 99 37 687 15.8 31° (3.2.2)(1H1.2)^3(2.3.2)
Krok, Friendship-2 3402 Krok, Friendship-2 LH, stamped steel frame, rubber grips, oval top & 2 round bottom holes, hybrid cam /w straight teeth, double-pin safety with pivot on side of cam Krok, 2021 331 189 157 33 990 15.2 31° (3.2.2)(1H1.2)^3(2.3.2)
LACD 1952
2195
LACD LH & RH, stamped frame, plastic grip, round top & bottom holes, hybrid cam /w sloping teeth, tab safety below cam
  • CampZ.com/Amazon.com, 2013
  • Bob Thrun Collection, 2017
199 190 89 27 449 16.5 34° (2)(2S2.1S1)^3(2.3)
Lixada 2937 Lixada LH (AL-15) & RH (AD-10), stamped frame, rubber grips, oval & round top & 2 round bottom holes, open-web cam /w sloping teeth, tab safety below cam monboly, 2019 241 202 93 25 478 15.4 27° (3)^3(1S1)^5(3)^2
Lucky Pern AD-10 & AL-15 162/165 Lucky Pern AD-10 & AL-15 LH & RH, stamped frame, oval & round top holes, round lower hole, braced cam /w sloping teeth & side mud grooves, pin safety below cam Barrabes.com, 2003 219 213 92 29 579 15 24° (3.2)^2(1.2)^2(B)
LMagideal 2922/3410 Magideal LH, stamped frame, rubber & plastic grips, oval top & 2 round bottom holes, hybrid cam /w straight teeth, push-button safety latch on cam
  • Motor Parts Value, 2019
  • Strade FarEast Ltd. (Jewelleri), 2021
224 195 104 33 669 14.0 30° (4.3)(1H1)(2.3.2.H)^2(3.2)^2
Molot 2058 Molot RH, stamped frame, textolite grip, subtriangular top hole, round bottom hole, open cam /w milled teeth, safety lever in cam channel Sarah Conner, 2016 237 208 103 26 566 16.8 mm 20 (2)(4)^17
Naxen 2363 Naxen LH & RH, stamped frame, round top & 2 round bottom holes, hybrid cam /w sloping teeth, tab safety below cam euromegashop / Amazon.com, 2018 204 190 89 27 455 16.1 30° (2.4)(1S1.2S2)^2(1S1)(2.3)
Newdoar 2362/3426 Newdoar LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, semi-open-web cam /w sloping teeth, tab safety below cam
  • LH: Newdoar / Amazon.com, 2018
  • RH: Meituo / Amazon.com, 2021
243 202 93 25 476 15.0 27° (3)^3(1S1)^5(3)^2
NTR, Version A 2014 NTR, Version A LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, open-web cam /w sloping teeth, tab safety below cam Linko Chen 训连 陈, 2015 239 202 94 25 492 14.6 27° (3)^3(1S1)^5(3)^2
NTR, Version B 2324/3412 NTR, Version B LH, stamped frame, round top & 2 round bottom holes, hybrid cam /w sloping teeth, tab safety below cam
  • Kangjin Liao, 2017
  • fmie2718, 2021
205 191 89 27 452 15.9 31° (2.4)(1S1.2S2)^2(1S1)(2.3)
Omni USA 201
2198
Omni USA LH & RH, stamped frame, rubber  grip, oval top & round bottom holes, open-web cam /w sloping teeth, tab safety below cam
  • Jeffrey Neff, 2005
  • Bob Thrun Collection, 2017
217 202 91 29 532 16.2 35° 3(4.H)^2(3.H)^2(2.2.1)
SunniMix 2964 Paliston LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, semi-open-web cam /w sloping teeth, tab safety below cam Cathy A Saffles, 2020 245 202 94 25 473 14.6 27° (3)^3(1S1)^5(3)^2
Petzl Ascension, Version A 2105 Petzl Ascension, Version A LH, stamped frame, plastic grip, round top & bottom holes, semi-open web cam /w sloping teeth, knob safety below cam Bob Thrun Collection, 2017 184 181 86 26 408 14.5 30° (3.4)^2(3.2)^2(1.2)
Petzl Ascension, Version B 2031
2183
Petzl Ascension, Version B LH & RH, polished stamped frame, plastic grip, round top & bottom holes, semi-open web cam /w sloping teeth, knob safety below cam
  • Julie E Rasmussen, 2015
  • Bob Thrun Collection, 2017
192 181 84 24 371 14.9 25° (F)(3.4)^3(3.2)^2(3)
Petzl Ascension, Version C 43 Petzl Ascension, Version C LH & RH, stamped frame, plastic grip, round top & bottom holes, semi-open web cam /w sloping teeth, knob safety below cam Speleoshoppe, 1979 187 180 87 34 522 15.6 25° (F)(3.4)^3(3.2)^2(3)
Petzl Ascension, Versions D1 & D2 296
1902
1906
2043
Petzl Ascension, Versions D1 & D2 LH & RH, stamped frame, plastic grip, oval + round top & round bottom holes, semi-open web cam /w sloping teeth, knob or pin safety below cam
  • Richard Bradley, 2009
  • Stuart Holmes, 2012
  • Daniel MacKinnon, 2012
  • CarolJo Rushin-Elron, 2016
187 190 87 30 497 14.5 24° (3.4)^2(3.2)^2(1.2)
Petzl Ascension, Versions E1 & E2 1513
1554
1946
Petzl Ascension, Versions E1 & E2 LH & RH, stamped frame, plastic grip, oval + round top & round bottom holes, semi-open web cam /w sloping teeth, knob or pin safety below cam
  • Bruce Ellison, 2009
  • Avri Keren, 2011
  • Travis Luther, 2013
  • Stuart Holmes, 2012
192 192 87 26 435 15.9 24° (3.4)^2(3.2)^2(1.2)
Petzl Ascension, Versions F1 & F2 44/45
1514
2353
Petzl Ascension, Versions F1 & F2 LH & RH, stamped frame, plastic grip, oval + round top & round bottom holes, pin cam stop, semi-open web cam /w sloping teeth, knob or pin safety below cam
  • Inner Mountain Outfitters, 1989
  • Richard Bradley, 2009
  • Daniel MacKinnon, 2012
197 192 87 35 593 16.8 28° (3.4)^2(3.2)^2(1.2)
Petzl Ascension, Version G 1507L
1568
1569
2184
Petzl Ascension, Version G LH & RH, stamped frame, plastic grip, oval + round top & round bottom holes, pin cam stop, hybrid cam /w sloping teeth, screw-pin safety below cam
  • Sheryle Bauer, 2009
  • James R. Armstrong, 2012
  • Dane Hardinge, 2012
  • Bob Thrun Collection, 2017
203 193 87 30 506 14.5 30° (2.3)(2S2.1S1)^2(1S1)^3(1.2)
Petzl Ascension, Version H 1507R
2184
Petzl Ascension, Version H RH, stamped frame, plastic grip, oval + round top & round bottom holes, pin cam stop, hybrid cam /w sloping teeth, screw-pin safety below cam
  • Sheryle Bauer, 2009
  • Bob Thrun Collection, 2017
203 193 87 30 506 14.5 30° (2.3)(2S2.1S1)^2(1S1)^3(1.2)
Petzl Ascension, Version I 46
2185
Petzl Ascension, Version I LH & RH, stamped frame, plastic grip, oval + round top & round bottom holes, pin cam stop, hybrid cam /w sloping teeth, screw-pin safety below cam
  • Bob & Bob, 1989
  • Bob Thrun Collection, 2017
201 192 88 35 588 14.8 30° (2.3)(2S2.1S1)^2(1S1)^3(1.2)
Petzl Ascension, Version J 1901 Petzl Ascension, Version J RH, stamped frame, plastic grip, oval + round top hole, round bottom hole, hybrid cam /w sloping teeth, screw-pin safety below cam Sam Smith, 2012 207 196 88 27 464 14.9 33° (2.3)(2S2.1S1)^2(1S1)^3(1.2)
Petzl Ascension, Version K 1571 Petzl Ascension, Version K LH & RH, stamped frame, plastic grip, oval + round top & round bottom holes, pin cam stop, hybrid cam /w sloping teeth, screw-pin safety below cam B. Bieger, 2012 210 195 89 28 489 14.9 33° (2.3)(2S2.1S1)^2(1S1)^3(1.2)
Petzl Ascension, Version L 169
2054
Petzl Ascension, Version L RH, stamped frame, plastic grip, oval + round top & round bottom holes, pin cam stop, hybrid cam /w sloping teeth, screw-pin safety below cam
  • Alan Shelby, 2004
  • Melody Madison, 2015
204 192 88 35 588 14.8 30° (2.3)(2S2.1S1)^2(1S1)^3(1.2)
Petzl Ascension, Version M 2924 Petzl Ascension, Version M LH, stamped frame, plastic grip, oval + round top & round bottom holes, barrel cam stop, hybrid cam /w sloping teeth, screw-pin safety below cam Jon Oshiro, 2019 207 195 90 27 468 15.7 33° (2.3)(2S2.1S1)^2(1S1)^3(1.2)
Petzl Ascension, Version M 266
1900
2925
Petzl Ascension, Version N LH & RH, stamped frame, plastic grip, oval + round top & round bottom holes, pin cam stop, hybrid cam /w sloping teeth, screw-pin safety below cam
  • J. Matzke, 2009
  • Jeffrey Kuchak, 2012
  • Jon Oshiro 2019
204 192 88 35 588 14.8 30° (2.3)(2S2.1S1)^2(1S1)^3(1.2)
Petzl Ascension, Version N 264 Petzl Ascension, Version O LH, stamped frame, plastic grip, oval + round top & round bottom holes, barrel cam stop, hybrid cam /w sloping teeth, screw-pin safety below cam Jay Kennedy, 2005 204 192 88 35 588 14.8 30° (2.3)(2S2.1S1)^2(1S1)^3(1.2)
Petzl Ascension, Version O 127
2186
Petzl Ascension, Version P LH & RH, stamped frame, rubber  grip, oval + round top & round bottom holes, stamped cam stop, semi-open web cam /w sloping teeth, plastic safety below cam
  • On Rope 1, 1998
  • Bob Thrun Collection, 2017
188 190 89 32 541 14.9 33° (2.3)(2S2.1S1)^2(1S1)^3(1.2)
Petzl Ascension, Version P 298
2112
Petzl Ascension, Version Q
(B17SLN, B17SRG)
LH & RH, stamped frame, rubber  grip, oval top hole, round & oval bottom holes, stamped cam stop, semi-open web cam /w sloping teeth, plastic safety below cam
  • On Rope 1, 2009
  • Bob Thrun Collection, 2017
197 192 89 31 525 15.4 30° (3.1.4)(1S1.1S0.2S2)^2(1S1)(2.3)
Petzl Ascension, Version Q 2010
2065
Petzl Ascension, Version R
(B17ALA, B17ARA)
LH & RH, stamped frame, rubber  grip, oval top hole, D-shaped bottom hole, semi-web cam /w sloping teeth, plastic safety below cam
  • Expé-Spelemat, 2015
  • Bob Thrun Collection, 2017
164 192 90 24 408 14.4 33° (3.4)(1S1)^2(2S2)(1S1)^4(3.4.3)
Petzl Ascentree (half) 1536 Petzl Ascentree (half) RH cut from dual-handled double-rope ascender, , stamped steel frame, rubber grips, oval top & 2 round bottom holes, stamped cam stop, semi-open web cam /w sloping teeth, plastic safety below cam Expé-Spelemat, 2010 197 189 99 23 437 15.0 30° (3.1.4)(1S1.1S0.2S2)^2(1S1)(2.3)
Petzl Pompe, Version A 47
2110
2182
Petzl Pompe, Version A RH, stamped frame, plastic grip, oval + round top & round bottom holes, pulley mount /w mechanical advantage rig, pin cam stop, hybrid cam /w sloping teeth, screw-pin safety below cam
  • Inner Mountain Outfitters, 1994
  • Bob Thrun Collection, 2017
  • Bob Thrun Collection, 2017
320 195 100 32 624 14.8 30° (2.3)(2S2.1S1)^2(1S1)^3(1.2)
Petzl Pompe, Version B 241
2297
Petzl Pompe, Version B RH, stamped frame, plastic grip, oval top & 2 round bottom holes, pulley mount /w mechanical advantage rig, stamped cam stop, semi-open web cam /w sloping teeth, plastic safety below cam
  • Steve Rogers, 2008
  • Bob Thrun Collection, 2017
316 192 104 29 583 14.9 33° (3)(2S2.1S1)^3(2.3)
PMI Cat, Version A 2310 PMI Cat, Version A LH, stamped frame, rubber grips, oval top & round bottom holes, hybrid cam /w straight teeth, pin safety with pivot on side of cam Bob Thrun Collection, 2017 288 192 93 40 706 18.3 26° (4.5)^4(4.3)^4
PMI Cat, Version B 164
2163
PMI Cat, Version B LH & RH, stamped frame, rubber grips, oval top & round bottom holes, hybrid cam /w straight teeth, pin safety with pivot on side of cam
  • Inner Mountain Outfitters, 2003
  • Bob Thrun Collection, 2017
288 192 93 40 706 18.3 26° (4.5)^4(4.3)^4
Proverti CD 211L & CD 212L 2022/2037 Proverti CD 211L & CD 212L LH & RH, stamped frame, round top & 2 round bottom holes, hybrid cam /w sloping teeth, tab safety below cam Ondřej Belica, 2015 204 191 89 27 457 15.9 30° (2.4)(1S1.2S2)^2(1S1)(2.3)
Rock Empire 1587
2194
Rock Empire LH & RH, stamped frame, rubber  grip, oval top hole, round & oval bottom holes, stamped cam stop, open-web cam /w sloping teeth, plastic-covered tab safety below cam
  • Climbing Terekpl, 2012
  • Bob Thrun Collection, 2017
212 193 87 28 465 13.7 28° (3)^3(1H1)^5(3)^2
Russian, Homemade 3446 Russian, Homemade LH, bent Al shell, no handgrip, perforated plate cam /w straight teeth, safety lever in cam channel Artyom Babin (Артём Бабин), 2021 221 196 123 25 590 13.7 15° (3)^11
Singing Rock Lift 2026 Singing Rock Lift, Version A LH & RH, stamped frame, rubber grips, pear top & 2 round bottom holes, stamped cam stop, hybrid cam /w sloping teeth, double pin safety with pivot on side of cam Alpinsport Basis GmbH, 2015 219 189 90 30 511 15.6 31° (3.4.2)(1H1.2)^3(3.2)
Singing Rock Lift, Version B 2919/2920 Singing Rock Lift, Version B LH, stamped frame, plastic grip, round top & subtriangular bottom hole, semi-web cam /w sloping teeth, plastic safety below cam Buffalo Gap Outfitters, 2019 191 193 89 29 496 15.1 30° (3.4.2)(1H1.2)^3(3.2)
SOB, Version A 1933
2192
SOB, Version A LH & RH, stamped frame, rubber grip, oval top hole, round bottom holes, stamped cam stop, semi-web cam /w sloping teeth, tab safety below cam
  • Camping Survivals, 2012
  • Bob Thrun Collection, 2017
208 192 95 23 416 15.0 29° (4)(1S1.2S2.1S1)(4)(1S1)^4(4)
SOB, Version B 2051 SOB, Versions B LH & RH, stamped frame, rubber grip, oval top hole, round bottom holes, stamped cam stop, semi-web cam /w sloping teeth, tab safety below cam amazon.com, 2016 214 192 96 24 449 15.0 29° (4)(1S1.2S2.1S1)(4)(1S1)^4(4)
SOB, Version C 2057 SOB, Version C LH & RH, stamped frame, rubber grip, oval top hole, round bottom holes, stamped cam stop, semi-web cam /w sloping teeth, tab safety below cam amazon.com, 2016 214 192 96 24 449 15.0 29° (4)(1S1.2S2.1S1)(4)(1S1)^4(4)
Spelet Horní 1941
1953/1954
Spelet Horní LH & RH, stamped frame, plastic grip, oval and round top holes, round bottom hole, semi-open web cam /w sloping teeth, knob safety below cam
  • Philipp Molzer, 2013
  • Ondřej Belica, 2013
205 196 91 25 442 15.0 27° (F)(3.4)^3(3.2)^2(3)
Spent Ruční 1956 Spent Ruční RH, stamped frame, plastic grip, round top holes, round bottom hole, Al plate cam /w hard insert teeth, pin safety below cam Ondřej Belica, 2013 210 197 94 28 520 15.2 22° (3.2)^5
Spent Ruční 2961 Strmeň Žiara
LH, stamped frame, rubber grip, round holes, drilled plate cam /w hard insert teeth, metal safety on frame Ondřej Belica / Climbing CZ sro, 2020 211 192 74 30 426 13.6 22° (2.1)^4(2)
SunniMix 2364 SunniMix LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, open-web cam /w sloping teeth, tab safety below cam Echain International Ltd., 2018 244 202 96 24 462 14.4 30° (3)^3(1S1)^5(3)^2
SUT 2326 SUT LH & RH, stamped frame, rubber & plastic grips, oval top & round bottom holes, hybrid cam /w straight teeth, push-button safety latch on cam Kangjin Liao, 2017 223 196 101 32 637 13.5 30° (4.3)(1H1)(2.3.2.H)^2(3.2)^2
Trango, Version B 2025 Trango Passport LH & RH, stamped frame, rubber grip, oval top hole, round bottom holes, hybrid cam /w sloping teeth, plastic safety below cam Ondřej Belica / Climbing CZ sro, 2015 211 194 86 27 455 14.8 29° (3.4)(1S1.2S2.(1S1)^2)(3.2.3)
Tupa 2921 Tupa LH & RH, stamped frame, rubber grip, oval top hole, round bottom holes, hybrid cam /w straight teeth, tab safety below cam Strade FarEast Ltd. (Jewelleri), 2019 214 192 93 27 481 14.0 25° (3.4)(1S1.1S1)(4)(1S1)^3(2.3.2.2.3)
Turin, Version A 2929 Turin, Version A RH, stamped frame, rubber grip, oval top & round bottom holes, stamped cam stop, semi-open web cam /w sloping teeth, tab safety below cam Artyom Babin (Артём Бабин), 2019 238 195 90 29 505 17.2 mm 30 (3)(1S1)^4(2S2)(3.2.4.3)
Turin, Version B 2934 Turin, Version B LH, stamped frame, rubber grip, oval top & round bottom holes, stamped cam stop, semi-open web cam /w sloping teeth, tab safety below cam Artyom Babin (Артём Бабин), 2019 228 195 89 29 495 16.6 mm 30 (3)(1S1)^4(2S2)(3.2.4.3)
Unknown Chinese, Version A 2365 Unknown Chinese, Version A RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, open-web cam /w sloping teeth, tab safety below cam happyhausstores, 2018 243 203 96 24 465 14.4 30° (3)^3(1S1)^5(3)^2
Unknown Chinese, Version B 2926 Unknown Chinese, Version B LH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, open-web cam /w sloping teeth, tab safety below cam beautylady365, 2018 239 204 93 25 474 14.4 27° (3)^3(1S1)^5(3)^2
Uola, Version A 2161 Uola, Version A RH, stamped frame, plastic grip, round top & bottom holes, semi-open web cam /w sloping teeth, knob safety below cam Bob Thrun Collection, 2017 178 188 86 27 442 15.4 26° (4.3)^2(2)(2S2)^2(1S1)^2(2.3)^2(2)
Uola, Version B 49
2160
Uola, Version B RH, stamped frame, plastic grip, round top & bottom holes, semi-open web cam /w sloping teeth, knob safety below cam
  • John E. Weinel, Inc., 1989
  • Bob Thrun Collection, 2017
176 190 87 29 479 15.5 28° (4.3)^2(2)(2S2)^2(1S1)(2.3)^2(2)
Uola, Version C 2162 Uola, Version C RH, stamped frame, plastic grip, round top & bottom holes, semi-open web cam /w sloping teeth, knob safety below cam Bob Thrun Collection, 2017 179 189 86 27 431 15.5 26° (4.3)^2(2)(2S2)^2(1S1)^2(2.3)^2(2)
Ural-Alp 10.32, Version A 178 Ural Alp 10.32, Version A RH, stamped Al frame, round top & bottom holes, open-web cam /w sloping teeth, flat spring safety /w hold-open pin on cam Ural Sport, 2004 256 181 119 40 862 17.0 25° (3.2)^2.2.1.2.2.3.2.1.2
Ural-Alp 10.32, Version B 188 Ural Alp 10.32, Version B RH, stamped Al frame, round top & bottom holes, open-web cam /w sloping teeth, tab safety below cam Ural Sport, 2005 263 179 119 30 639 16.8 25° (3.2)^2.2.1.2.2.3.2.1.2
Ural-Alp 10.32, Version C 2367 Ural Alp 10.32, Version C RH, stamped Al frame, round top & bottom holes, open-web cam /w sloping teeth, pin safety below cam Марина Храмцова (Marina Khramstova), 2018 263 184 120 34 759 15.0 25° (3.2)^2.2.1.2.2.3.2.1.2
VauDe, Version A 1992 VauDe, Version A LH, stamped frame, oval & round top holes, round lower hole, semi-web cam /w sloping teeth, pin safety below cam Michael Fisher, 2015 213 198 92 31 567 15.0 28° (2.3)(4.3)^2(2.3.2.1.2)
VauDe, Version B 1993 VauDe, Version B RH, stamped frame, oval & round top holes, round lower hole, semi-web cam /w sloping teeth, pin safety below cam Michael Fisher, 2015 203 198 92 32 586 15.0 28° (2.3)(4.3)^2(2.3.2.1.2)
Vento Ascension 1559/1560 Vento Ascension LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, open-web cam /w sloping teeth, tab safety below cam Backountry (Russia), 2011 240 202 93 26 484 14.8 28° (3)^3(1S1)^5(3)^2
Vertical, Version A  (a.k.a. Kirov) 187 Vertical, Version A  (a.k.a. Kirov) RH, stamped frame, rubber grip, oval top & 2 round bottom holes, pin cam stop, semi-web cam /w straight teeth, cast Al safety below cam Ural Sport, 2005 231 194 93 30 547  15.4 31°  (3)(2S1.1S1)^3(2S2)(3)
Vertical, Version B 2932 Vertical, Version B RH, stamped frame, rubber grip, oval top & 2 round bottom holes, pin cam stop, semi-web cam /w straight teeth, cast Al safety below cam Artyom Babin (Артём Бабин), 2019 219 196 94 29 527 14.6 30° (3)(2S2.1S1)^3(4.3)
Vertical, Version C 2931 Vertical, Version C RH, stamped frame, rubber grip, oval top & 2 round bottom holes, pin cam stop, semi-web cam /w straight teeth, cast Al safety below cam Artyom Babin (Артём Бабин), 2019 229 196 98 29 555 14.5 30° (3)(2S2.1S1)^3(4.3)
Vertical, Version D 2311 Vertical, Version D RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, pin cam stop, semi-web cam /w straight teeth, plastic safety below cam
  • Ice Rock, 2017
  • Artyom Babin, 2019
208 192 94 28 512 15.7 34° (3.4)(1S1.2S2)^2(1S1)^2(3)
Walkosz i Spółka 2104 Walkosz i Spółka LH & RH, stamped frame, plastic grip, oval + round top & round bottom holes, hybrid cam /w sloping teeth, screw-pin safety below cam Bob Thrun Collection, 2017 199 196 88 25 435 15.7 27° (1S1.2S2)^2(1S1)^4(1.2)
Xinda, Version A 2938
2939
Xinda, Version A LH & RH, stamped frame, rubber grip, oval top & D bottom holes, semi-web cam /w sloping teeth, tab safety below cam
  • SaveMoneyForYou, 2019
  • welltopshophk17, 2019
212 192 95 28 505 14.2 32° (3.4)((1S1)^2(4)(1S1)^4(5.4.3)
Xinda, Version B 2965 Xinda, Version B LH & RH, stamped frame, rubber grips, oval top & D bottom holes, hybrid cam /w straight teeth, pin safety with pivot on side of cam Amazon.com, 2020 206 192 91 33 572 14.3 33° (3.4)(1S1)^2(4)((1S1)^3(2.3.2.2.3)
Xinda, Version C 3441 Xinda, Version C RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, semi-open-web cam /w sloping teeth, tab safety below cam Edgar Gutierrez, 2021 243 202 94 29 546 15.3 27° (3)^3(1S1)^5(3)^2
Yoke 1939
2196
Yoke LH & RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, asymmetrical open-web cam /w sloping teeth, tab safety below cam
  • Camping Survivals, 2012
  • Bob Thrun Collection, 2017
240 204 93 25 492 15.8 27° (3)^3(1H1)^5(3)^2
Z&W, Version A 2366 Z&W, Version A RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, asymmetrical open-web cam /w sloping teeth, tab safety below cam beautylady365, 2018 239 204 93 25 474 14.4 27° (3)^3(1S1)^5(3)^2
Z&W, Version B 3411 Z&W, Version B RH, stamped frame, rubber grips, oval & round top & 2 round bottom holes, semi-open-web cam /w sloping teeth, tab safety below cam Abraham Teitelbaum (אברהם טייטלבאום), 2021 243 202 94 28 539 15.3 27° (3)^3(1S1)^5(3)^2

Handled eccentric Cam Ascender Weight Chart Double Cast Milled
